| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | TP 3105S |
| Display Colors | Color Display |
| Display Size | 10.4 Inch Display |
| HMI Type | Touch Screen HMI |
| Series | |
| Technology | TFT LCD Display |
| UPC Code | 4055626055954 |
Overview
Phoenix Contact’s TP3000 series HMI operator panels are available in screen sizes ranging from 5.7 to 15 inches in 4:3 and 16:9 aspect ratio. These rugged HMIs cover a wide range of applications from general purpose to wide-temp/sun-light readable to Marine-grade. The TP3000 feature 24VDC operation, all metal design and are available with resistive touch screen or with a capacitive touch screen that supports gesture capability. The free VISU EXPRESS screen design software provides easy creation of graphic screens and features trending, alarming, logging, and recipe handling. Support communication protocols include Ethernet IP, Modbus TCP, as well as OPC DA. In addition, a free App allows you to mirror screens from the HMI to your smart device.
